TE Connectivity AMP Connectors 1-1734598-0
- 1-1734598-0
- TE Connectivity AMP Connectors
- CONN HEADER 10PS 1.25MM VERT T/H
- Rectangular Connectors - Headers, Male Pins
- 1-1734598-0 Datenblatt
- -
- -
- Lead free / RoHS Compliant
- 11845
- Spot-Inventar/autorisierte Händler/Werksüberschuss-Inventar
- 1-Jahres-Qualitätssicherung 》
- Klicken Sie hier, um Preise zu erhalten
Part Number 1-1734598-0 |
Category Rectangular Connectors - Headers, Male Pins |
Manufacturer TE Connectivity AMP Connectors |
Description CONN HEADER 10PS 1.25MM VERT T/H |
Package - |
Series High Performance Interconnect (HPI) |
Operating Temperature -25°C ~ 85°C |
Mounting Type Through Hole |
Termination Solder |
Style Board to Cable/Wire |
Current Rating 1A |
Contact Material Phosphor Bronze |
Number of Positions 10 |
Voltage Rating 100VAC |
Connector Type Header |
Number of Positions Loaded All |
Number of Rows 1 |
Insulation Color Natural |
Contact Type Male Pin |
Material Flammability Rating UL94 V-0 |
Pitch - Mating 0.049" (1.25mm) |
Shrouding Shrouded - 4 Wall |
Contact Length - Post 0.067" (1.70mm) |
Insulation Height 0.185" (4.70mm) |
Contact Shape Square |
Contact Finish - Mating Tin |
Contact Finish - Post Tin |
Insulation Material Polyamide (PA9T), Nylon 9T, Glass Filled |
Contact Finish Thickness - Mating 120µin (3.05µm) |
Package_case - |
1-1734598-0 Garantien
• Antworten Sie umgehend
• Garantierte Qualität
• Globaler Zugang
• Wettbewerbsfähiger Marktpreis
• One-Stop-Support für die Lieferkette
Jinftry, es ist Ihr vertrauenswürdigster Zulieferer. Bitte senden Sie uns die Anfrage. Vielen Dank!
Haben Sie Fragen zu 1-1734598-0 ?
Fühlen Sie sich frei uns zu kontaktieren:
+86-755-82518276
+8615019224070, annies65, +8615118125813
568248857, 827259012, 316249462
+8615019224070, +8615118118839, +8615118125813
( E-Mail zuerst wird dankbar sein )
Bemerkungen
TE Connectivity AMP Connectors
TE Connectivity AMP Connectors - TE Connectivity AMP, formerly Tyco Electronics AMP is the world's leader in the development and manufacture of a wide variety of electronic/electrical connectors and interconnection systems. Products ...
103635-5
CONN HEADER RT/A .100 6POS 15AU
1-86479-3
CONN HEADER RT/A .100 6POS 15AU
1-292132-4
CONN HEADER RT/A .100 6POS 15AU
1-292133-4
CONN HEADER RT/A .100 6POS 15AU
1-1586043-2
CONN HEADER RT/A .100 6POS 15AU
3-292208-6
CONN HEADER RT/A .100 6POS 15AU
1-1318300-7
