Molex 1722992212
- 1722992212
- Molex
- ULTRAFIT VERT 15 AU PLATED NAT
- Rectangular Connectors - Headers, Male Pins
- 1722992212 Datenblatt
- -
- -
- Lead free / RoHS Compliant
- 1695
- Spot-Inventar/autorisierte Händler/Werksüberschuss-Inventar
- 1-Jahres-Qualitätssicherung 》
- Klicken Sie hier, um Preise zu erhalten
Part Number 1722992212 |
Category Rectangular Connectors - Headers, Male Pins |
Manufacturer Molex |
Description ULTRAFIT VERT 15 AU PLATED NAT |
Package - |
Series Ultra-Fit? 172299 |
Features Board Guide, Solder Retention |
Operating Temperature -40°C ~ 120°C |
Mounting Type Through Hole |
Termination Solder |
Style Board to Cable/Wire |
Contact Material Copper Alloy |
Number of Positions 12 |
Voltage Rating 400V |
Connector Type Header |
Number of Positions Loaded All |
Number of Rows 2 |
Insulation Color Natural |
Contact Type Male Pin |
Fastening Type Latch Holder |
Material Flammability Rating UL94 V-0 |
Pitch - Mating 0.138" (3.50mm) |
Shrouding Shrouded - 4 Wall |
Contact Length - Post 0.126" (3.20mm) |
Insulation Height 0.465" (11.80mm) |
Contact Shape Square |
Contact Finish - Mating Gold |
Contact Finish - Post Tin |
Insulation Material Liquid Crystal Polymer (LCP) |
Contact Finish Thickness - Mating 15µin (0.38µm) |
Row Spacing - Mating 0.181" (4.60mm) |
Package_case - |
