TE Connectivity AMP Connectors 207398-1
- 207398-1
- TE Connectivity AMP Connectors
- CONN HDR PIN 10POS METRIMATE TIN
- Rectangular Connectors - Headers, Male Pins
- 207398-1 Datenblatt
- -
- -
- Lead free / RoHS Compliant
- 29351
- Spot-Inventar/autorisierte Händler/Werksüberschuss-Inventar
- 1-Jahres-Qualitätssicherung 》
- Klicken Sie hier, um Preise zu erhalten
Part Number 207398-1 |
Category Rectangular Connectors - Headers, Male Pins |
Manufacturer TE Connectivity AMP Connectors |
Description CONN HDR PIN 10POS METRIMATE TIN |
Package - |
Series Metrimate |
Features Mounting Flange |
Operating Temperature -55°C ~ 130°C |
Mounting Type Through Hole, Right Angle |
Termination Solder |
Style Board to Board or Cable |
Current Rating 7.5A |
Contact Material Brass |
Number of Positions 10 |
Voltage Rating 600V |
Connector Type Header |
Number of Positions Loaded All |
Number of Rows 1 |
Insulation Color Red |
Contact Type Male Pin |
Fastening Type Latch Holder |
Material Flammability Rating UL94 V-0 |
Pitch - Mating 0.197" (5.00mm) |
Shrouding Shrouded - 4 Wall |
Contact Length - Post 0.192" (4.88mm) |
Insulation Height 0.500" (12.70mm) |
Contact Shape Circular |
Contact Finish - Mating Tin-Lead |
Contact Finish - Post Tin-Lead |
Insulation Material Polyamide (PA), Nylon |
Contact Finish Thickness - Mating 150µin (3.81µm) |
Package_case - |
