Würth Elektronik 691359740002
- 691359740002
- Würth Elektronik
- TERM BLOCK PLUG 2POS 5.08MM
- Terminal Blocks - Headers, Plugs and Sockets
- 691359740002 Datenblatt
- -
- -
- Lead free / RoHS Compliant
- 1497
- Spot-Inventar/autorisierte Händler/Werksüberschuss-Inventar
- 1-Jahres-Qualitätssicherung 》
- Klicken Sie hier, um Preise zu erhalten
Part Number 691359740002 |
Category Terminal Blocks - Headers, Plugs and Sockets |
Manufacturer Würth Elektronik |
Description TERM BLOCK PLUG 2POS 5.08MM |
Package - |
Series WR-TBL Series 3597 |
Type Plug, Female Sockets |
Features Mating Flange, Retention Latches (Non-Wire Side) |
Operating Temperature -40°C ~ 115°C |
Mounting Type Free Hanging (In-Line) |
Termination Style IDC |
Color Green |
Number of Positions 2 |
Pitch 0.200" (5.08mm) |
Wire Gauge or Range - AWG 18-22 AWG |
Wire Gauge or Range - mm² 0.3 ~ 0.8mm² |
Current - UL 7A |
Voltage - UL 300V |
Number of Levels 1 |
Positions Per Level 2 |
Contact Mating Finish Tin |
Plug Wire Entry 90° |
Package_case - |
