3M 929667-01-06-I
- 929667-01-06-I
- 3M
- CONN HEADER 12POS DUAL .100 R/A
- Rectangular Connectors - Headers, Male Pins
- 929667-01-06-I Datenblatt
- -
- -
- Lead free / RoHS Compliant
- 1244
- Spot-Inventar/autorisierte Händler/Werksüberschuss-Inventar
- 1-Jahres-Qualitätssicherung 》
- Klicken Sie hier, um Preise zu erhalten
Part Number 929667-01-06-I |
Category Rectangular Connectors - Headers, Male Pins |
Manufacturer 3M |
Description CONN HEADER 12POS DUAL .100 R/A |
Package - |
Series 929 |
Operating Temperature -40°C ~ 105°C |
Mounting Type Through Hole, Right Angle |
Termination Solder |
Style Board to Board |
Current Rating 2.5A |
Contact Material Copper Alloy |
Number of Positions 12 |
Connector Type Header |
Number of Positions Loaded All |
Number of Rows 2 |
Insulation Color Black |
Contact Type Male Pin |
Fastening Type Push-Pull |
Material Flammability Rating UL94 V-0 |
Pitch - Mating 0.100" (2.54mm) |
Shrouding Unshrouded |
Contact Length - Mating 0.235" (5.97mm) |
Contact Length - Post 0.110" (2.79mm) |
Insulation Height 0.215" (5.45mm) |
Contact Shape Square |
Contact Finish - Mating Gold |
Contact Finish - Post Gold |
Insulation Material Polybutylene Terephthalate (PBT), Polyester, Glass Filled |
Contact Finish Thickness - Mating 10µin (0.25µm) |
Row Spacing - Mating 0.100" (2.54mm) |
Package_case - |
929667-01-06-I Garantien
• Antworten Sie umgehend
• Garantierte Qualität
• Globaler Zugang
• Wettbewerbsfähiger Marktpreis
• One-Stop-Support für die Lieferkette
Jinftry, es ist Ihr vertrauenswürdigster Zulieferer. Bitte senden Sie uns die Anfrage. Vielen Dank!
Haben Sie Fragen zu 929667-01-06-I ?
Fühlen Sie sich frei uns zu kontaktieren:
+86-755-82518276
+8615019224070, annies65, +8615118125813
568248857, 827259012, 316249462
+8615019224070, +8615118118839, +8615118125813
( E-Mail zuerst wird dankbar sein )
Bemerkungen
3M
3M is a leading supplier of innovative solutions for the electrical, electronics, and communications industries. A diversified technology company, 3M has a worldwide presence in several markets, including OEM (electrical and electronics), consumer ...
