3M 929805-01-35-I
- 929805-01-35-I
- 3M
- CONN HEADER 35POS .100" GOLD
- Rectangular Connectors - Headers, Male Pins
- 929805-01-35-I Datenblatt
- -
- -
- Lead free / RoHS Compliant
- 17527
- Spot-Inventar/autorisierte Händler/Werksüberschuss-Inventar
- 1-Jahres-Qualitätssicherung 》
- Klicken Sie hier, um Preise zu erhalten
Part Number 929805-01-35-I |
Category Rectangular Connectors - Headers, Male Pins |
Manufacturer 3M |
Description CONN HEADER 35POS .100" GOLD |
Package - |
Series 929 |
Operating Temperature -40°C ~ 105°C |
Mounting Type Through Hole |
Termination Solder |
Style Board to Board |
Current Rating 2.5A |
Contact Material Copper Alloy |
Number of Positions 35 |
Connector Type Header, Breakaway |
Number of Positions Loaded All |
Number of Rows 1 |
Insulation Color Black |
Contact Type Male Pin |
Fastening Type Push-Pull |
Material Flammability Rating UL94 V-0 |
Pitch - Mating 0.100" (2.54mm) |
Shrouding Unshrouded |
Contact Length - Mating 0.093" (2.36mm) |
Contact Length - Post 0.110" (2.79mm) |
Insulation Height 0.115" (2.92mm) |
Contact Shape Square |
Contact Finish - Mating Gold |
Contact Finish - Post Gold |
Insulation Material Polybutylene Terephthalate (PBT), Polyester, Glass Filled |
Overall Contact Length 0.318" (8.08mm) |
Contact Finish Thickness - Mating 10µin (0.25µm) |
Package_case - |
