Hirose Electric Co Ltd A1-10PA-2.54DS(71)
- A1-10PA-2.54DS(71)
- Hirose Electric Co Ltd
- HEADER RA 10 POS 2.54MM
- Rectangular Connectors - Headers, Male Pins
- A1-10PA-2.54DS(71) Datenblatt
- -
- -
- Lead free / RoHS Compliant
- 22885
- Spot-Inventar/autorisierte Händler/Werksüberschuss-Inventar
- 1-Jahres-Qualitätssicherung 》
- Klicken Sie hier, um Preise zu erhalten
Part Number A1-10PA-2.54DS(71) |
Category Rectangular Connectors - Headers, Male Pins |
Manufacturer Hirose Electric Co Ltd |
Description HEADER RA 10 POS 2.54MM |
Package - |
Series A1 |
Operating Temperature -55°C ~ 85°C |
Mounting Type Through Hole, Right Angle |
Termination Solder |
Style Board to Board or Cable |
Current Rating 3A |
Contact Material Brass |
Number of Positions 10 |
Voltage Rating 200V |
Connector Type Header |
Number of Positions Loaded All |
Number of Rows 2 |
Insulation Color Black |
Contact Type Male Pin |
Fastening Type Push-Pull |
Material Flammability Rating UL94 V-0 |
Pitch - Mating 0.100" (2.54mm) |
Shrouding Unshrouded |
Contact Length - Mating 0.236" (6.00mm) |
Contact Length - Post 0.118" (3.00mm) |
Insulation Height 0.236" (6.00mm) |
Contact Shape Square |
Contact Finish - Mating Gold |
Contact Finish - Post Tin |
Insulation Material Polybutylene Terephthalate (PBT) |
Contact Finish Thickness - Mating 8µin (0.20µm) |
Row Spacing - Mating 0.100" (2.54mm) |
Package_case - |
