Luminus Devices Inc. CBT-140-WDH-C15-QA220
- CBT-140-WDH-C15-QA220
- Luminus Devices Inc.
- BIG CHIP LED DAY WHITE
- LED Lighting - COBs, Engines, Modules
- CBT-140-WDH-C15-QA220 Datenblatt
- -
- -
-
Lead free / RoHS Compliant
- 780
- Spot-Inventar/autorisierte Händler/Werksüberschuss-Inventar
- 1-Jahres-Qualitätssicherung 》
- Klicken Sie hier, um Preise zu erhalten
Teilenummer CBT-140-WDH-C15-QA220 |
Kategorie LED Lighting - COBs, Engines, Modules |
Hersteller Luminus Devices Inc. |
Beschreibung BIG CHIP LED DAY WHITE |
Paket - |
Serie CBT-140 |
Typ LED Module |
Merkmale With Connector |
Größe/Dimension 28.00mm L x 42.00mm W |
Konfiguration Square |
Stromtest 21A |
Farbe White, Cool |
Höhe 5.70mm |
Spannung – Vorwärts (Vf) (Typ) 3.6V |
Lumen/Watt @ Strom - Test 29 lm/W |
Farbtemperatur (K) 5600K |
Fluss @ Strom/Temperatur - Test 2180 lm (2100 lm ~ 2260 lm) |
Temperatur - Test 85°C |
CRI (Farbwiedergabeindex) 92 |
Lichtemittierende Oberfläche (LES) 4.25mm Diameter |
Objektivtyp Flat |
CBT-140-WDH-C15-QA220 Garantien
• Antworten Sie umgehend
• Garantierte Qualität
• Globaler Zugang
• Wettbewerbsfähiger Marktpreis
• One-Stop-Support für die Lieferkette
Jinftry, es ist Ihr vertrauenswürdigster Zulieferer. Bitte senden Sie uns die Anfrage. Vielen Dank!
Haben Sie Fragen zu CBT-140-WDH-C15-QA220 ?
Fühlen Sie sich frei uns zu kontaktieren:
+86-755-28503874
+8615019224070, annies65, +8615118125813
568248857, 827259012, 316249462
+8615019224070, +8615118118839, +8615118125813
( E-Mail zuerst wird dankbar sein )
Bemerkungen
Luminus Devices Inc.

Luminus Devices is a company dedicated to innovation and manufacturing of high brightness LED technology.
In 2002, Luminus Devices was founded in California, USA. The company's products mainly include high-performance LED chips and modules,...
