Hirose Electric Co Ltd DF1B-26DP-2.5DSA(01)
Das Bild dient nur als Referenz, bitte beachten Sie die Produktspezifikation
- DF1B-26DP-2.5DSA(01)
- Hirose Electric Co Ltd
- CONN HEADER 26POS 2.5MM STR GOLD
- Rectangular Connectors - Headers, Male Pins
- DF1B-26DP-2.5DSA(01) Datenblatt
- -
- -
-
Lead free / RoHS Compliant - 1558
- Spot-Inventar/autorisierte Händler/Werksüberschuss-Inventar
- 1-Jahres-Qualitätssicherung 》
- Klicken Sie hier, um Preise zu erhalten
Lieferservice:
Zahlungsarten:
| Part Number DF1B-26DP-2.5DSA(01) |
| Category Rectangular Connectors - Headers, Male Pins |
| Manufacturer Hirose Electric Co Ltd |
| Description CONN HEADER 26POS 2.5MM STR GOLD |
| Package - |
| Series DF1B |
| Features Keying Slot |
| Operating Temperature -35°C ~ 85°C |
| Mounting Type Through Hole |
| Termination Solder |
| Style Board to Cable/Wire |
| Contact Material Brass |
| Number of Positions 26 |
| Voltage Rating 250V |
| Connector Type Header |
| Number of Positions Loaded All |
| Number of Rows 2 |
| Insulation Color White |
| Contact Type Male Pin |
| Fastening Type Push-Pull |
| Material Flammability Rating UL94 V-0 |
| Pitch - Mating 0.098" (2.50mm) |
| Shrouding Shrouded - 4 Wall |
| Contact Length - Mating 0.177" (4.50mm) |
| Contact Length - Post 0.142" (3.60mm) |
| Insulation Height 0.374" (9.50mm) |
| Contact Shape Square |
| Contact Finish - Mating Gold |
| Insulation Material Polyamide (PA), Nylon |
| Overall Contact Length 0.417" (10.60mm) |
| Contact Finish Thickness - Mating 8µin (0.20µm) |
| Row Spacing - Mating 0.098" (2.50mm) |
| Package_case - |
DF1B-26DP-2.5DSA(01) Garantien
• Antworten Sie umgehend
• Garantierte Qualität
• Globaler Zugang
• Wettbewerbsfähiger Marktpreis
• One-Stop-Support für die Lieferkette
Jinftry, es ist Ihr vertrauenswürdigster Zulieferer. Bitte senden Sie uns die Anfrage. Vielen Dank!
Haben Sie Fragen zu DF1B-26DP-2.5DSA(01) ?
Fühlen Sie sich frei uns zu kontaktieren:
+86-755-82518276
+8615019224070, annies65, +8615118125813
568248857, 827259012, 316249462
+8615019224070, +8615118118839, +8615118125813
( E-Mail zuerst wird dankbar sein )
DF1B-26DP-2.5DSA(01) Verwandte Produkte
Bemerkungen
Hirose Electric Co Ltd
Hirose Electric Company specializes in the manufacture of connectors and has been a contributor to the development of the electronics sector for over 70 years. Their modest and humble business philosophy of seeking wisdom ...
.jpg)
PX10-AD4WP(50)
CONN RECEPT RT ANG 8POS PCB
.jpg)
PX10-AF6WP(50)
CONN RECEPT RT ANG 8POS PCB
.jpg)
DF1B-18DP-2.5DS(01)
CONN RECEPT RT ANG 8POS PCB
DF11-8DP-2V(57)
CONN RECEPT RT ANG 8POS PCB
DF11Z-18DP-2V(27)
CONN RECEPT RT ANG 8POS PCB
ST60X-36S
CONN RECEPT RT ANG 8POS PCB
.jpg)
HR31-5.08R-5PD(72)
CONN RECEPT RT ANG 8POS PCB
ST60X-18S
