TE Connectivity Deutsch Connectors DT15-12PD-B016
- DT15-12PD-B016
- TE Connectivity Deutsch Connectors
- DT RECP ASM
- Rectangular Connectors - Headers, Male Pins
- DT15-12PD-B016 Datenblatt
- -
- -
- Lead free / RoHS Compliant
- 3344
- Spot-Inventar/autorisierte Händler/Werksüberschuss-Inventar
- 1-Jahres-Qualitätssicherung 》
- Klicken Sie hier, um Preise zu erhalten
Part Number DT15-12PD-B016 |
Category Rectangular Connectors - Headers, Male Pins |
Manufacturer TE Connectivity Deutsch Connectors |
Description DT RECP ASM |
Package - |
Series * |
Features Mounting Flange |
Operating Temperature -55°C ~ 125°C |
Mounting Type Panel Mount, Through Hole |
Termination Solder |
Style Board to Cable/Wire |
Number of Positions 12 |
Voltage Rating 250VDC |
Connector Type Header |
Number of Positions Loaded All |
Number of Rows 2 |
Insulation Color Brown |
Contact Type Male Pin |
Fastening Type Latch Holder |
Pitch - Mating 0.175" (4.44mm) |
Shrouding Shrouded - 4 Wall |
Contact Length - Post 0.122" (3.10mm) |
Insulation Height 1.371" (34.82mm) |
Contact Shape Circular |
Insulation Material Plastic |
Row Spacing - Mating 0.360" (9.14mm) |
Package_case - |
