Harwin Inc. M80-6660442
- M80-6660442
- Harwin Inc.
- DIL MALE HORIZ SMT CONNECTOR
- Rectangular Connectors - Headers, Male Pins
- M80-6660442 Datenblatt
- -
- -
- Lead free / RoHS Compliant
- 4485
- Spot-Inventar/autorisierte Händler/Werksüberschuss-Inventar
- 1-Jahres-Qualitätssicherung 》
- Klicken Sie hier, um Preise zu erhalten
Part Number M80-6660442 |
Category Rectangular Connectors - Headers, Male Pins |
Manufacturer Harwin Inc. |
Description DIL MALE HORIZ SMT CONNECTOR |
Package - |
Series Datamate L-Tek |
Features Strain Relief Clips |
Operating Temperature -55°C ~ 125°C |
Mounting Type Surface Mount, Right Angle |
Termination Solder |
Style Board to Board or Cable |
Current Rating 2.2A per Contact |
Contact Material Brass |
Number of Positions 4 |
Voltage Rating 800V |
Connector Type Header |
Number of Positions Loaded All |
Number of Rows 2 |
Insulation Color Black |
Contact Type Male Pin |
Fastening Type Latch Lock |
Material Flammability Rating UL94 V-0 |
Pitch - Mating 0.079" (2.00mm) |
Shrouding Shrouded - 4 Wall |
Insulation Height 0.235" (5.97mm) |
Contact Shape Circular |
Contact Finish - Mating Gold |
Contact Finish - Post Tin |
Insulation Material Polyphenylene Sulfide (PPS), Glass Filled |
Contact Finish Thickness - Mating 29.5µin (0.75µm) |
Row Spacing - Mating 0.079" (2.00mm) |
Package_case - |
